Our products
We provide a wide range of industrial standard metrology equipment. The products are designed for Laser Scanners, artifical arms and other metrology equipment. We are constantnly extending our product portfolio so check out and come back frequently to stay updated.
HDT - Heavy Duty Tripods
Using METROLOGYBASE Portable Heavy Duty Tripods improve your flexibility at measurement area. METROLOGYBASE has designed these portable heavy duty metrology tripods for functionality, portability and repeatable measurement. Portable Heavy Duty Tripods are available in a number of standard configurations.
| Product | Short / Tall | Fixed / Adjustable | Upper Legs | Weight | Load Capacity |
|---|---|---|---|---|---|
| MB-HDT-SF-AL | Short | Fixed | Aluminum | 16.0 kg | 80.0 kg |
| MB- HDT-TF-AL | Tall | Fixed | Aluminum | 19.2 kg | 80.0 kg |
| MB-HDT-SF-CF | Short | Fixed | Carbon Fiber | 14.0 kg | 80.0 kg |
| MB-HDT-TF-CF | Tall | Fixed | Carbon Fiber | 17.0 kg | 80.0 kg |
| MB-HDT-SA-AL | Short | Adjustable | Aluminum | 19.8 kg | 50.0 kg |
| MB-HDT-TA-AL | Tall | Adjustable | Aluminum | 23.0 kg | 50.0 kg |
| MB-HDT-SA-CF | Short | Adjustable | Carbon Fiber | 18.0 kg | 50.0 kg |
| MB-HDT-TA-CF | Tall | Adjustable | Carbon Fiber | 21.0 kg | 50.0 kg |
HDS - Heavy Duty Stands
METROLOGYBASE has designed rigid and stable Heavy Duty Metrology Stands to meet all of your metrology needs. These heavy duty metrology stands satisfy your needs when stability, sturdiness, durability and weight are of primary importance. Heavy Duty Metrology Stands are available in a number of standard configurations.
| Product | Fixed / Adjustable | Height | Weight | Load Capacity |
|---|---|---|---|---|
| MB-HDS-F10" | Fixed | 10" | 45.0 kg | 120.0 kg |
| MB-HDS-F20" | Fixed | 20" | 57.0 kg | 120.0 kg |
| MB-HDS-F27" | Fixed | 27" | 62.0 kg | 120.0 kg |
| MB-HDS-F32" | Fixed | 32" | 68.0 kg | 120.0 kg |
| MB-HDS-20"-25" | Adjustable | 20"-25" | 68.0 kg | 70.0 kg |
| MB-HDS-28"-42" | Adjustable | 28"-42" | 72.0 kg | 70.0 kg |
| MB-HDS-36"-54" | Adjustable | 36"-54" | 81.0 kg | 70.0 kg |
| MB-HDS-43"-67" | Adjustable | 34"-67" | 85.0 kg | 70.0 kg |
Magnetic Bases
Using METROLOGYBASE Magnetic Bases improve your flexibility at measurement area. METROLOGYBASE has designed these Magnetic Bases for functionality, portability and repeatable measurement of CMMs. Magnetic Bases are available in four standard configurations.
| Product | Flat / Curved | Adapter | Magnet Force | Weight | Ring |
|---|---|---|---|---|---|
| MB-MB-01-A1 | Flat | 1 | 980 N x 3 | 6.4 kg | 3 1/2" - 8 thread |
| MB-MB-01-A2 | Flat | 2 | 980 N x 3 | 6.4 kg | 3 1/2" - 8 thread |
| MB-MB-02-A1 | Curved | 1 | 1470 N x 2 | 10.2 kg | 3 1/2" - 8 thread |
| MB-MB-02-A2 | Curved | 2 | 1470 N x 2 | 10.1 kg | 3 1/2" - 8 thread |
Mounting plates
METROLOGYBASE Mounting Plates have been designed for Portable CMMs and Laser Trackers. Mounting Plates are ideal where you want to make measurements on non-magnetic surfaces.
| Product | Flat / Curved | Adapter | Magnet Force | Weight | Ring |
|---|---|---|---|---|---|
| MB-MB-01-A1 | Flat | 1 | 980 N x 3 | 6.4 kg | 3 1/2" - 8 thread |
| MB-MB-01-A2 | Flat | 2 | 980 N x 3 | 6.4 kg | 3 1/2" - 8 thread |
| MB-MB-02-A1 | Curved | 1 | 1470 N x 2 | 10.2 kg | 3 1/2" - 8 thread |
| MB-MB-02-A2 | Curved | 2 | 1470 N x 2 | 10.1 kg | 3 1/2" - 8 thread |
CMM base plates
METROLOGYBASE CMM Base Plates are available in sizes from 300 mm x 300 mm to 900 mm x 1200 mm. All plates designed to allow mounting very small parts to heavy components.
| Product | Thread | Width | Depth | Thickness | Thread Spacing |
|---|---|---|---|---|---|
| MB-CBP-13300300-12-M6 | M6 | 300 mm | 300 mm | 13 mm | 12.5 mm |
| MB-CBP-13450450-12-M6 | M6 | 450 mm | 450 mm | 13 mm | 12.5 mm |
| MB-CBP-19600600-12-M6 | M6 | 600 mm | 600 mm | 19 mm | 12.5 mm |
| MB-CBP-19750750-12-M6 | M6 | 750 mm | 750 mm | 19 mm | 12.5 mm |
| MB-CBP-197501000-12-M6 | M6 | 750 mm | 1000 mm | 19 mm | 12.5 mm |
| MB-CBP-199001200-12-M6 | M6 | 900 mm | 1200 mm | 19 mm | 12.5 mm |
| MB-CBP-13300300-15-M8 | M8 | 300 mm | 300 mm | 13 mm | 15.0 mm |
| MB-CBP-13450450-15-M8 | M8 | 450 mm | 450 mm | 13 mm | 15.0 mm |
| MB-CBP-19600600-15-M8 | M8 | 600 mm | 600 mm | 19 mm | 15.0 mm |
| MB-CBP-19750750-15-M8 | M8 | 750 mm | 750 mm | 19 mm | 15.0 mm |
| MB-CBP-197501020-15-M8 | M8 | 750 mm | 1000 mm | 19 mm | 15.0 mm |
| MB-CBP-199001200-15-M8 | M8 | 900 mm | 1200 mm | 19 mm | 15.0 mm |
Quick base plates
METROLOGYBASE designed Quick Base Plates to increase speed and flexibility when loading parts onto CMM.
| Product | Thread | Width | Length | Thickness | Thread Spacing |
|---|---|---|---|---|---|
| MB-QBP-13150150-12-M6 | M6 | 150 mm | 150 mm | 12.7 mm | 12.5 mm |
| MB-QBP-13300300-12-M6 | M6 | 300 mm | 300 mm | 12.7 mm | 12.5 mm |
| MB-QBP-13450450-12-M6 | M6 | 450 mm | 450 mm | 12.7 mm | 12.5 mm |
| MB-QBP-13300300-15-M8 | M8 | 300 mm | 300 mm | 12.7 mm | 15.0 mm |
| MB-QBP-13450450-15-M8 | M8 | 450 mm | 450 mm | 12.7 mm | 15.0 mm |
Fixture Tables
METROLOGYBASE Fixture Tables are ideal for portable CMMs. Their construction gives flexibility to mount CMM and parts. Their rigid construction gives ability to stand under extra heavy parts. You can also use our fixture tables with Gantry and Horizontal CMMs.
| Product | Thread | Width | Length | Height | Thread Spacing |
|---|---|---|---|---|---|
| MB-MFT-1200900-25-M6 | M6 | 1200 mm | 900 mm | 900 mm | 25.0 mm |
| MB-MFT-1500900-25-M6 | M6 | 1500 mm | 900 mm | 900 mm | 25.0 mm |
| MB-MFT-18001200-25-M6 | M6 | 1800 mm | 1200 mm | 900 mm | 25.0 mm |
| MB-MFT-1200900-30-M8 | M8 | 1200 mm | 900 mm | 900 mm | 30.0 mm |
| MB-MFT-1500900-30-M8 | M8 | 1500 mm | 900 mm | 900 mm | 30.0 mm |
| MB-MFT-18001200-30-M8 | M8 | 1800 mm | 1200 mm | 900 mm | 30.0 mm |
Accessories
For all our products we offer a wide range of accessories. Please see our full catalouge or contact us for more details.
We offer also customized adapters so your equipment, if metrology or any other industry fits to our tripods, stands and tables. Our CAD department is happy to help.
